Please Note: The Zavio D4210 is no longer manufactured. Please refer to the Zavio dome camera page for a replacement.
The Zavio-D4210 Mini Vandal Dome IP Camera is capable of recording at
30 frames per second in 1080P video resolution (Sample Video). The Zavio D4210 Mini Vandal Dome IP Camera features a 1/2.8" SONY Exmor CMOS image sensor and a 3.6mm Fixed Lens.
This camera can support up to 4 simultaneous video streams of each
H.264 or MJPEG. It has infrared illuminators with an effective range of 10 meters / 30 feet to provide an exceptional image in low light and pitch black environments. The Micro SD card slot allows the user to record video clips and snapshots locally.
An IK8 enclosure protects the camera's vital components from acts of vandalism (Please Note: The Zavio D4210 is NOT Weatherproof). The Zavio D4210 can be powered by either 12V-DC or POE (Power over Ethernet), which allows both video and power to be run over one Cat-5 cable. For use with external sensors and alarms, the D4210 has one alarm input and one alarm output.
Like all Zavio IP Cameras, the D4210
includes 64 channel recording software to give the user the features of a network video recorder.
Zavio-D4210 Specification
- 1/2.8" SONY Exmor CMOS Image Sensor
- 3.6mm Fixed Lens
- 1920 x 1080 at 30FPS Recording
- 10 Meter / 30 Foot IR Range
- Micro SD Card Slot
- POE 802.3af Compliant
- Built-in Web Server
- 81° Horizontal Angle of View
- Remote Viewable from Windows PCs
- Remote Viewable from Mac Computers
- 3 Axis Mount for Wall or Ceiling
- H.264 and MJPEG Video Streams
- 1 Alarm Input / 1 Alarm Output
- Compatible with iCamViewer iPhone App
- Multi Language Interface
- Supports ONVIF
- 64 Channel NVR Software Included
NVR Software / IP Camera Recording Software Included!
All Zavio IP cameras include NVR / IP camera recording software that supports up to 64 cameras for live viewing, recording, and playback. Some of the features included in the software are: 64 camera remote channel live view, 16 channel playback simultaneously, motion detection & scheduled recording, supports H.264/ MPEG-4/ MJPEG compression formats, multiple user access levels with password protection, iPhone, iPad, and Android mobile apps, and powerful recording search functions. This NVR software runs on Windows PCs.
You can learn more about the included Zavio NVR software here.
Remote Live Viewer App
The Zavio software also includes the Remote Live Viewer app for Windows. This software connects to Zavio stand-alone NVRs and PC based NVRs (built with the free Zavio software). It enables live remote viewing of all IP cameras connected to your NVR(s). The software also includes the Remote Playback app which lets users search and playback surveillance video that has been recorded to the NVR's hard drive.
You can learn more about the Remote Live Viewer software here.
Mac Compatible IP Camera
Zavio IP cameras support live remote viewing over the Internet from a Mac computer. Macintosh users can directly access Zavio IP cameras using Safari, Chrome, and Firefox web browsers. For users that setup the Zavio NVR software on a Windows PC or use a stand-alone Zavio network video recorder, Mac users can also remotely access these NVRs to view all of the IP cameras, playback recorded video, and configure their NVR from Macintosh.
Learn more about remotely viewing IP cameras from Mac here.
Please note that Zavio camera DO NOT include video recording software for Mac. It is highly recommended that Mac users read our Zavio IP camera FAQ for Mac.
This video demonstrates live security camera viewing capability from the iPhone app that connects to the NVR software included with Zavio cameras.
You can learn more about the iPhone IP camera viewer app here.
Important Note:
Click the gear icon in the lower right of the video player and select 720p or 1080p resolution so that you can view the video in the highest resolution available.
Android App
Here is a screenshot of the Android app the connects to the NVR software included with Zavio IP cameras and enables remote live viewing and recorded video playback.
You can learn more about the Android IP camera viewer app here.
Complete IP Camera Systems
Did you know? CCTV Camera Pros can provide a complete IP camera system quote that includes any
Zavio IP cameras, a Zavio NVR or a custom PC based NVR build using the 64 channel IP camera software included with this camera. We can also include any number and model of cameras, CAT-5 cables, PoE switches, and monitors. Let us customize a system based on your project requirements.
Product Specification
Zavio D4210 Mini Vandal Dome IP Camera Specification
PoE for IP Camera
This IP camera is PoE (power over Ethernet) compliant which allows the installer to run a single CAT-5e cable to provide both power and data connectivity to the camera. CCTV Camera Pros supplies the following PoE injectors and PoE network switches which are compatible with this camera.
Please refer to these diagrams, to learn more about
how to wire IP cameras using a PoE injectors or a PoE switch.
