Please Note: The Geovision GV-MDR120 has been discontinued. Please refer to the Geovision Dome Camera page for a replacement.
The Geovision GV-MDR120 is a fixed dome IP camera featuring a 1.3 megapixel lens with a 1/3" progressive scan CMOS image sensor. The Geovision GV-MDR120 supports up to
30FPS (Frames Per Second) at
1280 x 1024 picture resolution.
This camera can be ceiling mounted as well as wall surface mounted. The
IP66 and
IK7 rated camera housing ensures optimal performance in outdoor temperatures of -4 to 122 degrees Fahrenheit. A
built-in microphone allows users to easily detect and record audio.
It also features a
3-axis mechanism allowing users to easily dial in the best viewing angle whether mounted on the ceiling or wall (
Mounting Positions). The GV-MDR120 supports dual video streams of H.264, MPEG4 or MJPEG.
This camera also features motion detection, tampering alarm, privacy mask and text overlay options. The GV-MDR120 supports
iPhone,
iPad,
Android and 3GPP mobile platforms. Click here to
watch a demo video surveillance clip captured using a GV-MDR120.
Geovision GV-MDR120 Features
- Weatherproof (for indoor or outdoor use), IP66 / IK7 Rated
- 1/3" progressive scan CMOS
-
1.3 Fixed Megapixel Lens
-
Dual video streams from two of H.264, MPEG4 and MJPEG
-
Up to 30 fps at 1280 x 1024
- Wall surface or ceiling mountable
-
Includes 32 Channel Geovision NVR Software
-
Mobile Phone Remote Viewing from iPhone and Android mobile platforms
-
3-axis mechanism (pan / tilt / roll)
-
Built-in microphone
-
Micro SD/SDHC card slot (Class 6 and above)
-
Motion detection
-
Tampering alarm
-
Privacy mask
-
IP address filtering
-
3GPP
-
POE IEEE 802.3af compliant
-
16 languages on Web interface
The following youTube video demonstrates the picture quality of the GV-MDR120. For the best video quality, select the 720p video format and expand the video to full screen.
Mounting Positions
Click on the images above to enlarge.
Camera Dimensions
Click on the images above for a larger view.
32 Channel Geovision Software
Each Geovision camera includes a free 32 channel software license which can be used with any Geovision IP camera. Install the software on a Windows computer and create a PC based surveillance DVR / NVR for your Geovision cameras. Click here to view the latest
Geovision software specification.
Remote Viewing Support
Geovision includes many options to view your cameras remotely over a local network and also remotely over the Internet. Remote viewing is supported by both Windows and Mac based PCs. Geovision also includes support to view cameras from cell phones and other mobile devices including: iPhone, iPad, iPod Touch, Android, Blackberry, Windows Mobile, Symbian, and other 3G / 3GPP cell phones. Geovision provides free apps for all of these types of devices. Some remote viewing methods require use of the NVR software that is included with the camera and some methods can connect directly to the camera and do not require a PC be used. Click here for more information on
Geovision remote viewer options.
PoE for IP Camera
This IP camera is PoE (power over Ethernet) compliant which allows the installer to run a single CAT-5e cable to provide both power and data connectivity to the camera. CCTV Camera Pros supplies the following PoE injectors and PoE network switches which are compatible with this camera.
Please refer to these diagrams, to learn more about
how to wire IP cameras using a PoE injectors or a PoE switch.
